PIONEER SX- 980

The unique receiver of this Japanese tycoon of the audio market, the highly rated model of the cult series with the number 80 at the end, equipped with analog power indicators, marked its place in the history of audio, very difficult to obtain now .... vintage equipment (yes, he is 40 years old! )

The classic format, highly appreciated throughout the world by experts for the great, uncompromising, beautiful performance characteristic of this brand.

The equipment was manufactured for the Western market for exceptionally demanding customers. It is a charming model, an absolutely unique piece, solid wood cabinet in exotic color with a perfect coat of paint, heavy front panel of brushed aluminum, thick glass pane, all thick aluminum knobs, knob strengthening and tuning full, very heavy!

Pioneer is a vintage equipment, a classic class, very appreciated all over the world by experts for a great, uncompromising, beautiful performance characteristic for this brand * very convenient mute switch (-20 db) and great loudness-these functions as well as other filters included The equipment was manufactured for the western market for exceptionally demanding customers. It is a charming model, an absolutely unique specimen, a casing made of decent wood in an exotic color with a perfect coat of paint, with a heavy front panel of brushed aluminum, thick glass pane, all thick aluminum knobs, full and heavy tuning knob, very heavy!, knurled, also all lever switches are made of aluminum

* high wattage power of 95 watts for 4 Ohms, for two sets of loudspeakers (resistively exceptionally friendly), for any resistance of 4 to 16 Ohm speaker sets with outstanding sound color, with backlit power indicators, control and stereo signal, as well as also the type of sound source and choice of work of A / B loudspeaker sets with a very wide frequency range, and linear operation characteristics in a wide range. A great independent phono preamplifier for cooperation with every turntable, very wide frequency response (5-80,000 Hz) with minimal harmonic distortion , a powerful reserve of power.

This unique equipment is also characterized by an extremely perfect layout of components.

great FM signal, which distinguishes the extraordinary stability and sensitivity, thanks to the use of a pair of MOS FET double gates in its RF amplifier and mixer, advanced FM section, which includes three 2-element ceramic filters and large-scale integrated circuit, plus a multiplex section for FM broadcasts stereo, which uses an innovative and advanced IC phase synchronization loop for excellent separation properties.

The result is a flawless sound that is unmatched in sound quality with any comparably priced amplifier on the market, plus beautiful design and the perfection of human engineering ...

this amplifier is practically unavailable in such a unique technical and visual condition, we offer a lot of models of other receivers, but this one is unique, has undergone extensive revitalization work, has been perfectly restored, including tuner section tuning, amplifier section thoroughly tested, the equipment has been demolished in order to eliminate cold solder, thorough cleaning, the upper cover has a new varnish coating, the casing has reinforced, thoroughly preserved wood, beautiful exotic veneer with an impeccable varnish coating, absolutely unique version, for a connoisseur who wishes to have a personalized, unique receiver sufficient power and an exceptionally charming sound, can certainly become a pride of every living room or office of the Lord, I highly recommend! This model is hardly available on world markets, in our country at this price unattainable at present!

POWERFUL POWER RESERVE 800 W!

This receiver is practically unattainable in such a technical and visual condition, we offer a lot of models of other receivers and interesting amplifiers.

We offer a lot of models of other receivers, but this one is unique, has undergone extensive revitalization work, perfectly serviced, including tuner section tuning, amplifier section thoroughly tested, equipment was dismantled to remove cold solder, thorough cleaning, top cover has a new coating varnish, the casing has reinforced, thoroughly preserved wood, beautiful exotic veneer with a pristine coat of varnish, absolutely unique version, for a connoisseur-esthete who wishes to have a personalized, unique powerful power amplifier and extremely charming sound.

Producer: Pioneer
Model: SX-980
Type: receiver
Construction year: 1978 - 1980
Manufactured in: Japan
Color: front silver, wooden casing
Remote control: no
Power consumption: 800 watts max.
Dimensions: 526 x 176 x 440 mm (S x W xD)
Weight: 18.8 kg
Original price about 2'385 DM

Number of inputs: 4
2x Phono (MM): 2.5 mV / 50 kOhm

2x Tape, Aux: 150 mV / 50 kOhm

Antenna (VHF: 75, 300 ohms, AM)

Microphone: 7.5 mV / 50 kOhm

Number of outputs: 2
2x Tape Rec: 150mV

Headphones (6.3 mm jack)

2 pairs of speakers

Technical data

Amplifier

Continuous power (with a distortion factor):
8 ohms: 2 x 80 watts

4 ohms: 2 x 95 W

Dynamic power:
8 ohms: 2 x 160 watts

4 ohms: 2 x 190 watts

Total harmonic distortion: 0.05%
damping factor:
Frequency response: 5 - 80,000 Hz (± 0,5 dB)
Signal to noise ratio:
Stereo channel separation:
tone regulation:
Bass: yes (200/400 Hz to choose from)

Heights: yes (5/25 kHz to choose from)

Volume: yes
High filter: yes (6 kHz)
Lower filter (subsonic): yes (15 Hz)
Mute: yes (-20 dB)
Direct / Line Straight: no

Tuner

Reception: FM / MW
frequency:
FM: 88-108 MHz

MW: 535 - 1605 KHz

Input sensitivity:
FM: 1.7μV

MW: 15μV

distortion:
FM (1 kHz): <0.10% (mono), <0.15% (stereo)

Signal to noise ratio:
FM (65 dB): 80 dB (mono), 71 dB (stereo)

MW: 55 dB

Channel separation: 50 dB (1 kHz)
selectivity:
Selection of a single wave: 1.0 dB
False choice:
FM: 80 dB

Image rejection:
VHF: 90 dB

MW: 40 dB

IF suppression:
FM: 110 dB

MW: 40 dB

AM attenuation: 55 dB
Special functions

Initial and final separation (Main In / Pre Out)
